PHAP5-10RA2B2S2N4 5mm Button 3.5mm x 6mm Right Angle Surface Mount Tactile Switch APEM
by APEM
SKU 486111
MPN: PHAP5-10RA2B2S2N4
Availability:
900 in stock
Original price
£0.53
-
Original price
£0.53
Original price
£0.53
£0.53
-
£0.53
Current price
£0.53
The PHAP5-10RA2B2S2N4 is a right angle tactile switch with a 3.5mm x 6mm standard package and 5mm length button. The switch provides a positive tactile feedback and is supplied in tape and reel packaging, suitable for SMT mounting.
Right angle SMT mounting
3.5mm x 6mm package
5mm length button
Rating: 50mA 12VDC
Operating force: 160g
Travel: 0.25mm
APEM PHAP5-10 series
Specification
Actuation | Momentary |
Back Order Lead Time | 10 Days |
Contact Configuration | SPST |
Contact Material | Silver Plated Stainless Steel |
Contact Rating | 50mA 12VDC |
Current Rating | 50mA |
Height | 5mm |
Material | Polyamide |
MOQ | 5 |
Mounting Style | PCB |
Number of Poles | 1 |
Number of Positions | 2 |
Operating Force | 160g |
Operating Temperature | -25°C to +70°C |
Product Series | PHAP5-10 |
Switch Operation | Off-(On) |
Terminal Type | Surface Mount |
Voltage Rating | 12VDC |
