PHAP5-30RA2B2S2N4 APEM 5mm Button 6mm x 6mm Right Angle Surface Mount Tactile Switch 160g

by APEM
SKU 486125

MPN: PHAP5-30RA2B2S2N4

Back Order Availability: 10 Days

Availability:
495 in stock, ready to be shipped
Original price £0.38 - Original price £0.38
Original price
£0.38 Inc VAT
£0.38 - £0.38
Current price £0.38 Inc VAT
The PHAP5-30RA2B2S2N4 is a right angle tactile switch with a 6mm x 6mm standard package and 5mm height. The switch provides a positive tactile feedback and is supplied in tape and reel packaging, suitable for SMT mounting.

  • Right angle SMT mounting
  • 6mm x 6mm package
  • 5mm height
  • Rating: 50mA 12VDC
  • Operating force: 160g
  • Travel: 0.25mm
  • APEM PHAP5-30 series
  • Specification
    Actuation Momentary
    Back order lead time 10 Days
    Contact configuration SPST
    Contact material Silver Plated Phosphor Bronze
    Contact rating 50mA 12VDC
    Current rating 50mA
    Height 5mm
    Material Polyamide
    Mounting style Surface Mount
    Number of poles 1
    Number of positions 2
    Operating force 160g
    Operating temperature -25°C to +70°C
    Product series PHAP5-30
    Switch operation Off-(On)
    Terminal type Surface Mount
    Voltage rating 12VDC
