PRN050L0B24S APEM 5 Key Blue illuminated 24VDC Stainless Steel Keypad

by APEM
SKU 490150

MPN: PRN050L0B24S

Availability:
Only 3 left!
Original price £111.19 - Original price £111.19
Original price
£111.19
£111.19 - £111.19
Current price £111.19
The PRN050L0B24S is a stainless steel 5 key keypad by APEM, manufactured from 316L stainless steel and featuring blue illumination. They keypad can be rear or front mounted with a frame and is sealed to IP65. The keypad features 14mm diameter keys and very long lifespan.

  • No frame
  • Blue 12VDC illumination
  • Sealed to IP65
  • Material: 316L stainless steel
  • Output: 5 matrix (NO contacts)
  • Switching rating: 12VDC 50mA
  • Contact force: 3.5N
  • Connection: male connector
  • Specification
    Actuation Momentary
    Colour Blue
    Contact Material Gold Plated
    Current Rating 0.05A
    Illuminated Yes
    Illumination Colour Blue
    Illumination Voltage 12VDC
    Material Stainless Steel
    MOQ 1
    Mounting Style Panel
    Operating Force 3.5N
    Operating Temperature -20°C to +70°C
    Panel Thickness 1.5 to 2.5mm
    Product Series PR
    Protection Level IP65
    Voltage Rating 12VDC
