PRN050L0B24S APEM 5 Key Blue illuminated 24VDC Stainless Steel Keypad
by APEM
SKU 490150
MPN: PRN050L0B24S
Availability:
Only 3 left!
Original price
£111.19
-
Original price
£111.19
Original price
£111.19
£111.19
£111.19
-
£111.19
Current price
£111.19
The PRN050L0B24S is a stainless steel 5 key keypad by APEM, manufactured from 316L stainless steel and featuring blue illumination. They keypad can be rear or front mounted with a frame and is sealed to IP65. The keypad features 14mm diameter keys and very long lifespan.
No frame Blue 12VDC illumination Sealed to IP65 Material: 316L stainless steel Output: 5 matrix (NO contacts) Switching rating: 12VDC 50mA Contact force: 3.5N Connection: male connector
Specification
| Actuation | Momentary |
| Colour | Blue |
| Contact Configuration | NO |
| Contact Material | Gold Plated |
| Contact Rating | 50mA 12VDC |
| Current Rating | 0.05A |
| Illuminated | Yes |
| Illumination Colour | Blue |
| Illumination Voltage | 12VDC |
| Material | Stainless Steel |
| MOQ | 1 |
| Mounting Style | Panel |
| Operating Force | 3.5N |
| Operating Temperature | -20°C to +70°C |
| Panel Thickness | 1.5 to 2.5mm |
| Product Series | PR |
| Protection Level | IP65 |
| Switch Operation | Off-(On) |
| Terminal Type | Connector |
| Voltage Rating | 12VDC |
