Red 5mm Water Clear LED 1000mcd 45°
by Luckylight
SKU 484843
MPN: 503VC2E-2BE
Availability:
3638 in stock
Original price
£0.13
-
Original price
£0.13
Original price
£0.13
£0.13
-
£0.13
Current price
£0.13
Red 5mm LED featuring a water clear package and 1000mcd luminous intensity suitable for applications including use as indicators, backlighting and illumination.
Luminous intensity: 1000mcd Wavelength: 624nm Viewing angle: 45° Forward voltage: 2.0V Forward current: 25mA Suitable for through-hole mounting Cathode identified as the shorter lead 2.54mm lead pitch Water clear lens Excellent weather resistance Long lifespan
Specification
| Back Order Lead Time | 40 Days |
| Colour | Red |
| Diameter | 5mm |
| Forward Current | 25mA |
| Forward Voltage | 2.0V |
| Lens Colour | Clear |
| Lens Shape | Round |
| Luminous Intensity | 1000mcd |
| Mode | Constant |
| MOQ | 5 |
| Mounting Style | Through Hole |
| Number of Pins | 2 |
| Operating Temperature | -40°C to +80°C |
| Package | 5mm |
| Packaging | Bulk |
| Power Dissipation | 60mW |
| Viewing Angle | 45° |
| Wavelength | 624nm |
