Red On-(On) 25mm Vandal Push Button Switch 2NO/2NC
SKU 483347
MPN: 483347
Availability:
55 in stock
Original price
£11.25
-
Original price
£11.25
Original price
£11.25
Inc VAT
£11.25
-
£11.25
Current price
£11.25
Inc VAT
Vandal resistant 25mm momentary push button switch manufactured from stainless steel, featuring a red LED and 2NO/2NC contacts. The switch features IP67 protection and is suitable for 12V applications.
Momentary On-(On) action Red LED 12V illumination voltage IP67 protection rating 25mm panel cut-out diameter 2NO/2NC contacts 2.8mm terminals Rating: 5A 250VAC
Specification
| Actuation | Momentary |
| Back order lead time | 30 Days |
| Colour | Red |
| Contact configuration | DPDT |
| Contact rating | 5A 250VAC |
| Current rating | 5A |
| Electrical life | 50,000 Cycles |
| Illuminated | Yes |
| Illumination colour | Red |
| Illumination voltage | 12VDC |
| Material | Stainless Steel |
| Mounting style | Panel |
| Number of positions | 2 |
| Operating temperature | -25°C to +85°C |
| Panel cut out | 25mm |
| Protection level | IP67 |
| Switch operation | On-(On) |
| Terminal type | Solder |
| Voltage rating | 250VAC |
