Roller Lever Subminiature PCB Microswitch SPDT 3A
SKU 481694
MPN: 481694
Availability:
4680 in stock
Original price
£0.54
-
Original price
£0.54
Original price
£0.54
£0.57
£0.57
-
£0.57
Current price
£0.57
Subminiature microswitch featuring a roller lever actuator housed in a compact package capable of switching up to 3A. The switch features solder terminals and is suitable for PCB applications.
14mm length roller lever actuator Rating: 3A 250VAC NO / NC contacts Solder PCB terminals Operating force: 30gf Release force: 10gf min Pre-travel: 2.7mm max Over-travel 1mm min Body dimensions: 12.8 x 5.8 x 6.5mm (Length x Width x Height)
Specification
| Back Order Lead Time | 45 Days |
| Contact Configuration | SPDT |
| Contact Rating | 3A 250VAC |
| Current Rating | 3A |
| Number of Positions | 2 |
| Operating Force | 30g Max |
| Pitch | 5.1mm |
| Release Force | 10gf Min |
| Terminal Type | Through Hole |
| Voltage Rating | 250VAC |
