UTP3305-II 3-Channel Linear DC Power Supply 5A 32V 335W Uni-T
by Uni-T
SKU 493817
MPN: UTP3305-II
Availability:
Only 2 left!
Original price
£195.50
-
Original price
£195.50
Original price
£195.50
£195.50
-
£195.50
Current price
£195.50
The UTP3305-II is a three-channel linear DC power supply featuring adjustable dual channels and fixed single-channel output. The power supply features tracking, constant voltage/current, series/parallel output, temperature controlled cooling fan, and over voltage/current protection.
3-channels Output voltage: CH1/CH2 0-32V, CH3 5V Output current: CH1/CH2 0-5A, CH3 3A Total power: 335W High precision 4-digit voltage and current display 10mV/1mA Low ripple and noise Parallel and series mode Output ON/OFF control
Specification
| Back Order Lead Time | 7 Days |
| Channels | 3 |
| Input Voltage | 220-230VAC |
| MOQ | 1 |
| Output Current | 0-5A |
| Output Voltage | 0-32VDC |
| Power Rating | 335W |
| Resolution | 10mV / 1mA |
