UV 5mm Water Clear LED 395nm 270mcd 25°

SKU 484894

MPN: 504UVAC2V-Q5D

Availability:
4165 in stock
Original price £0.19 - Original price £0.19
Original price
£0.19 Inc VAT
£0.19 - £0.19
Current price £0.19 Inc VAT
Ultra violet 5mm LED featuring a water clear package and 270mcd luminous intensity suitable for applications including use as indicators, backlighting and illumination.

  • Luminous intensity: 270mcd
  • Wavelength: 395nm
  • Viewing angle: 25°
  • Forward voltage: 3.2V
  • Forward current: 20mA
  • Suitable for through-hole mounting
  • Cathode identified as the shorter lead
  • 2.54mm lead pitch
  • Water clear lens
  • Excellent weather resistance
  • Long lifespan
  • Specification
    Back order lead time 40 Days
    Colour UV
    Diameter 5mm
    Forward current 20mA
    Forward voltage 3.2V
    Lens colour Clear
    Lens shape Round
    Luminous intensity 270mcd
    Mode Constant
    Moq 5
    Mounting style Through Hole
    Number of pins 2
    Operating temperature -40°C to +80°C
    Package 5mm
    Packaging Bulk
    Power dissipation 80mW
    Viewing angle 25°
    Wavelength 395nm
