VTX-126-006-209 Chassis Mount Transformer 230V 6VA 9V+9V Vigortronix
by Vigortronix
SKU 480235
MPN: VTX-126-006-209
Availability:
Out of stock
Sold out
Original price
£9.87
-
Original price
£9.87
Original price
£9.87
£9.87
£9.87
-
£9.87
Current price
£9.87
The VTX-126-006-209 is a high quality chassis mount transformer featuring a single 230V primary winding and 9V twin secondary winding. The transformer features 6VA power and can be connected in series or parallel.
Double section metric bobbins Primary winding: 230V Secondary winding: 9V+9V Power: 6VA Dielectric strength: 3750Vrms Manufactured and tested in accordance to EN61558, EN60950, CE
Specification
| Back Order Lead Time | 7 |
| Dielectric Strength | 3750Vrms |
| Height | 36mm |
| Length | 45mm |
| MOQ | 1 |
| Output Current | 0.33A |
| Power | 6VA |
| Primary Voltage | 230VAC |
| Secondary Voltage | 9V+9V |
| Weight | 170g |
| Width | 37mm |
