VTX-146-030-206 Toroidal Transformer 30VA 0-6V Vigortronix

SKU 487162

MPN: VTX-146-030-206

Availability:
9 in stock
Original price £17.72 - Original price £17.72
Original price
£17.72
£17.72 - £17.72
Current price £17.72
The VTX-146-030-206 is a high quality toroidal transformer featuring dual primary and secondary windings. The transformer features thermal fuses fitted to each primary winding, and a very low level radiated magnetic field. The transformers are widely used in industrial power, home appliances, instrumentation, communication and civil applications.

  • Dual primary winding: 115V+115V
  • Dual secondary winding: 0-6V 0-6V
  • Power: 30VA
  • Supplied with mounting kit
  • Dimensions: 33 x 74mm (Height x Diameter)
  • Compliant standards: EN61558, EN60950, UL, C-UL, UKCA and CE
  • Specification
    Back Order Lead Time 5 Days
    Diameter 74mm
    Height 33mm
    Output Current 2.5A
    Power 30VA
    Primary Voltage 2 x 115V
    Regulation 14%
    Secondary Voltage 2 x 6V
    Weight 450g
