VTX-146-030-215 Toroidal Transformer 30VA 0-15V Vigortronix
by Vigortronix
SKU 487164
MPN: VTX-146-030-215
Availability:
10 in stock
Original price
£17.72
-
Original price
£17.72
Original price
£17.72
£17.72
-
£17.72
Current price
£17.72
The VTX-146-030-215 is a high quality toroidal transformer featuring dual primary and secondary windings. The transformer features thermal fuses fitted to each primary winding, and a very low level radiated magnetic field. The transformers are widely used in industrial power, home appliances, instrumentation, communication and civil applications.
Dual primary winding: 115V+115V Dual secondary winding: 0-15V 0-15V Power: 30VA Supplied with mounting kit Dimensions: 33 x 74mm (Height x Diameter) Compliant standards: EN61558, EN60950, UL, C-UL, UKCA and CE
Specification
Back Order Lead Time | 5 Days |
Diameter | 74mm |
Height | 33mm |
Output Current | 1A |
Power | 30VA |
Primary Voltage | 2 x 115V |
Regulation | 14% |
Secondary Voltage | 2 x 15V |
Weight | 450g |
