W04M 400V Bridge Rectifier Diode 1.5A
SKU 480568
MPN: W04M
Availability:
211 in stock
Original price
£0.30
-
Original price
£0.30
Original price
£0.30
£0.30
-
£0.30
Current price
£0.30
The W04M is a plastic encapsulated 400V bridge rectifier diode featuring high overload ratings, suitable for mounting to printed circuit boards.
Moulded plastic case UL 94V-0 flame retardant Maximum recurrent peak reverse voltage: 400V Maximum average forward output current: 1.5A Dimensions: 5.0 x 8.6mm (Height x Diameter) Pitch: 5.1mm
Specification
| Back Order Lead Time | 5 Days |
| Maximum DC Blocking Voltage | 400V |
| Maximum Forward Voltage | 1.0V |
| Maximum RMS Voltage | 280V |
| MOQ | 5 |
| Operating Temperature | -55°C to 125°C |
