W08M 800V Bridge Rectifier Diode 1.5A
SKU 481719
MPN: W08M
Availability:
27 in stock
Original price
£0.28
-
Original price
£0.28
Original price
£0.28
£0.30
£0.30
-
£0.30
Current price
£0.30
The W08M is a plastic encapsulated 800V bridge rectifier diode featuring high overload ratings, suitable for mounting to printed circuit boards.
Moulded plastic case UL 94V-0 flame retardant Maximum recurrent peak reverse voltage: 800V Maximum average forward output current: 1.5A Dimensions: 5.0 x 8.6mm (Height x Diameter) Pitch: 5.1mm
Specification
| Average Rectified Current | 1.5A |
| Back Order Lead Time | 5 Days |
| Maximum DC Blocking Voltage | 800V |
| Maximum Forward Voltage | 1V |
| Maximum RMS Voltage | 560V |
| MOQ | 5 |
| Mounting Style | Through Hole |
| Operating Temperature | -55°C to 125°C |
| Package | Moulded Plastic Case |
| Packaging | Bulk |
| Peak Reverse Voltage | 800V |
| Peak Surge Current | 50A |
